Product features:
Operating conditions
Liquid temperature up to 60℃.
Ambient temperature up to 40℃.
Maximum self-priming lift up to 2 m.
Maximum working pressure up to 6 bar.
Motor 2-phase induction motor, 50 Hz, 2900 rpm. 400/V + 10% form 2.2 to 3.8kw. Insulation class F. Protection IP 54. Constructed in accordance with IEC 34.
High temperature resistant tooth flange (optional)
Impeller
AISI 304 stainless steel
