Product features:
Maximum working pressure: 2.5kg/cm²(35psi)
Maximum temperature: 45℃
Working pressure of 4kg/cm² available by special order.
- Anti - UV protective layer of fiber glass wound reinforced filter tank.
- Ergonomically designed six position multiport valve.
- Stainless steel oil filled psi/kpa dual scale pressure gauge.
- Internal piping for easy servicing.
- Automatic air bleed with manual safety pressure release.
- The industries largest ring-lock sealing clear top viewing port.
- Sand drain plug for easier sand removal replacement.
Three-dimensional nameplate
